Basic Info.
Model NO.
NY-72100
Rechargeable
Chargeable
Discharge Rate
Low Discharge Rate
Size
Large
Accessories Type
Battery
Rated Capacity
100ah
Standard Voltage
72V
Usage
Electric Forklift
Electrolyte
Li-ion
Cycle Life
2500 Times
Battery Cell
Grade a
The Charging Rate
1c
The Discharge Rate
1c
Transport Package
Safe Standard Export Cartons
Specification
Customized
Trademark
CNNTNY
Origin
Jiangsu, China
HS Code
8507600090
Production Capacity
50000 Piece/Per Month
Product Description
| Specification | |
| Nominal Voltage | 72V |
| Nominal Capacity(0.5C,25ºC) | 100Ah |
| Weight(Approximate) | ≤85kg |
| Dimension(Length*Width*Height) | Customized Accept |
| Standard Discharge@25ºC | |
| Max. Continuous Current | 100A |
| Cut-off Voltage | 60V±1V |
| Standard Charge | |
| Charge Voltage | 87.6V±0.2V |
| Recommended Charge Current | 40A |
| Charge Time | 5hours |
| Resistance and rates | |
| Internal Resistance | ≤120mΩ |
| Self-discharge rate | ≤5% per Month |
| General Features | |
| Assembly cell | 32700 6.5Ah |
| BMS specs | 100A |
