Basic Info.
Model NO.
LiFePO4-12200
OEM
Acceptable
Color
Grey / Black/Red
Terminal
Copper
Maintenance
Free
Warranty
5years
Material
Lithium Ion
Nominal Voltage
12V
Discharge Rate
High Discharge Rate
Electrolyte
Li-ion
Installation
Fixed
Shape
Cuboid
Transport Package
Carton Box and Wooden Pallet
Specification
522*240*224mm
Trademark
Jingsun battery
Origin
China
HS Code
8506500000
Production Capacity
5000PCS/Week
Product Description
Deep Cycle Li Ion Lithium 12V 200ah LiFePO4 Battery Pack for Power and Solar Storage
2. Clean and Green energy, no toxic material contained
3. Long life cycle, > 2000 times deep cycle at 1C rate, 6-8 times of lead acid battery
4. No memory effect, highly efficient charge anytime, no reduction of capacity
5. Operation temperature: -20~65ºC
6. Small size and light weight: 1/2 size of lead acid battery, 70% size of Ni-MH Ni-CD battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: < 3% monthly
Applications
1. Large-scale electric vehicles: Electric bus, electric car, E-Tour Car
2. Light electric car: E-bike, electric scooter, e-motor, electric golf car, forklift, cleanness car, electric wheelchairs
3. E-tool: Electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices
6. Small medical equipment and portable equipment
C: Could you print our company logo in nameplate and package?
D: Can you support OEM and on-site installation?
E: How does your factory carry out quality control?
| Function Parameter | |||
| Norminal Battery Energy | 2400wh | ||
| Norminal Capacity | 200Ah | ||
| Norminal Voltage | 12V | ||
| Internal Resistance | ≤20mΩ | ||
| Cycle Life | >2000 | ||
| Months Self Discharge | ≤3% | ||
| Charge Data | |||
| Charge Voltage | 14.6±0.2V | ||
| Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) | ||
| Charger Current | 50A | ||
| Max. Charge Current | 100A | ||
| Charge Cut-off Voltage | 15.6±0.2V | ||
| Discharge Data | |||
| Continuous Current | 100A | ||
| Max continuous discharge current | 120A | ||
| Discharge Cut-off Voltage | 8V | ||
| Working Condition | |||
| Charge Temperature | 0ºC to 45ºC (32ºF to 113ºF) @60±25% Relative Humidity | ||
| Discharge Temperature | -20ºC to 60ºC (-4ºF to 140ºF) @60±25% Relative Humidity | ||
| Storage Temperature | 0ºC to 40ºC (32ºF to 104ºF) @60±25% Relative Humidity | ||
| Enclosure Protection Level | IP65 | ||
| Mechanical Data | |||
| Cell & Method | 3.2V10Ah | ||
| Shell material | Iron | ||
| Dimensions | 522*240*224mm | ||
| Weight (lbs./kg.) | 27.1kgs | ||
Product Feature
1. Safety: Safest Li-ion battery, CE approved, built-in protection circuit board (BMS), no fire, no explosion2. Clean and Green energy, no toxic material contained
3. Long life cycle, > 2000 times deep cycle at 1C rate, 6-8 times of lead acid battery
4. No memory effect, highly efficient charge anytime, no reduction of capacity
5. Operation temperature: -20~65ºC
6. Small size and light weight: 1/2 size of lead acid battery, 70% size of Ni-MH Ni-CD battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: < 3% monthly
Applications
1. Large-scale electric vehicles: Electric bus, electric car, E-Tour Car
2. Light electric car: E-bike, electric scooter, e-motor, electric golf car, forklift, cleanness car, electric wheelchairs
3. E-tool: Electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices
6. Small medical equipment and portable equipment
Solar system, solar panel, inverter, controller, battery and mounting system and all the related soar power accessories.
B: Are you a factory or trading company?
We are a manufacturer with export license.And we have certificates.
C: Could you print our company logo in nameplate and package?
Yes, we can do it according to your design.
D: Can you support OEM and on-site installation?
Yes,as a professional solar system manufacturer, we can offer our clients OEM and on-site installation, fully support and assistance in service.
E: How does your factory carry out quality control?
Quality is priority. We have professional QC feam to carry out the Quality control.
F: What is your advantage in Solar Energy System?
Automatic production line with international advanced production equipment from Japan and Germany. Price is competitive.
